Compression Moulding
|
![Hydraulic Press](../img/technologies_compression_moulding.jpg) |
- Press with maximum clamping force of 2,500 tonnes
- Table size 3m X 2m
- Proactive parallelism control
- Moulding of demonstrator parts in industrial scale available
- Video
|
Direct SMC/SMC
|
![Thermoset Sheet Moulding Compound Equipmnet](../img/technologies_direct_smc.jpg) |
- First Direct SMC line in North America
- Production trials
- Material and process development
- 400 mm to 800 mm sheet width
|
LFT-D
|
![Long-Fibre Reinforced Thermoplastics Equipment](../img/technoloies_lft.jpg) |
- 2 extruder configuration (Dieffenbacher process)
- Industrial scale (75 mm diameter)
- Semi-structural part application
|
High Pressure RTM
|
![Resin Transfer Molding Equipment](../img/technologies_rtm.jpg) |
- Compression RTM
- High Pressure RTM
- Process development
- Alternative formulation development
|
Injection Moulding
|
![machine drawing](../img/machinedrawing_115x150.jpg) |
- Clamping unit with 16,000kN (parallelism control and negative embossing)
- Standard and MuCell injection unit with optimized long-fiber screw (Ø = 120 mm)
- Pressure accumulators for higher injection speed
- Fully automated manufacturing cell for continuous fiber reinforced parts (circulating hot air furnace and 6 axis handling robot)
|
Tape Laying - Fiberforge RELAY® Station
|
![fiberforge](../img/fibre-forge_115x150.jpg) |
- RELAY® technology
- Lay-up size up to 1m x 1m on two zones vacuum table
- Tape width: 50 - 150 mm
- Ultrasonic spot welding
|
Fiber Preforming
|
![Fiber preforming](../img/preform_table.jpg) |
- Fully automated fiber handling
- Damage-free fiber cutting
- Thermoplastic or thermosetting binders
- Preform shapes up to 2.5m x 2.5m
|
